VentEnterSearch’s own Eric Wheaton and Jimm Walsh will be teaching a H.O.T. class titled Can Confidence on October 11th, 2014 at the Florida State Fire College located in Ocala, (FL.) This class is designed to build confidence on one of the most often neglected tools found on nearly every fire apparatus, the 2 1/2 gallon water extinguisher. The “Can” can be an extremely effective lifesaving tool by allowing a well-trained fireman to quickly apply water between fire and victims.
Attendees will learn proper filling and pressurization steps, how to build homemade carrying straps and other useful “Can” modifications. The class will also cover valuable skills on carrying and searching with the “Can,” and confining fire with it as well. Students will cycle through a “force an interior door off its hinges” prop and use this door to hold back live fire and smoke. Finally, attendees will perform live fire attacks with nothing more than a “Can” and witness the effect of the “Can” on pre-flashover conditions.
Time: 9:00am or 1:00pm
Click Here to Register
Lt Tim Shaw from Westerville (OH) E112 sent in this door they recently found during a fire inspection. As you can see from the photo below, no indication of supplemental locks is obvious from the outside. We can tell that it is a metal door in a metal frame, but what is not so obvious is that it’s actually a masonry wall covered with wood siding.
The photo below clearly shows the supplemental locks once the door is opened. This particular set-up is the weaker version of slide bolt lock installation. These slide bolts are only surface screwed to the door. The “proper” way to install these slide bolts would be to drill all the way through the door, and to use large washers on the outside. This would prevent the bolts that secure the lock from easily being pulled through the door during the force. You may also notice that the hinge side slide bolts are still in the out position. These slide bolts do not have to be retracted in order for the door to be opened. They are only there to prevent/delay the door from being defeated from the hinge side.
Like most forcible entry scenarios, a well trained crew with a set of irons can make quick work of this door. With no visible indications of supplemental locks, a traditional force near the standard lock would be the most appropriate first action. Once the resistance if felt/noticed from the supplemental locks, its time to go to plan B. Simply changing the location of the irons to closer to the slide bolts and forcing traditionally would work just fine. Essentially the door will have to be forced in three locations. middle, top, and bottom. Going in the order mentioned (middle, top, bottom) would be the best choice. Middle first because until you do that, you wouldn’t even know the slide bolts were installed. Top would be next, because you are more fresh, have more energy, and are less likely to be obscured by smoke if you started low. Bottom would be last simply because its the easiest. Since these slide bolts are only surface mounted, they should pull out just fine.
This type of supplemental lock is typically found on the rear door of a commercial occupancy. Forcing the rear door on a commercial occupancy should be a high priority on a working fireground. Forcing the door early and re-closing after the locks have been defeated is an essential task. Obviously re-closing the door is suggested as to not contribute to flow path issues and negatively impact fire spread. Predict that interior crews will eventually needed this door open to supplement fire suppression efforts, or unfortunately for emergency egress. Forcing this door early, before it is actually needed will save us precious time later in the operation.
We will have a follow up post with a video on defeating this type of slide bolt supplemental lock in the near future. In the video we’ll share a more detailed explanation and share some additional tips on defeating them.1 comment
The rotary saw equipped with a metal cutting blade is an extremely important tool for us to have in our forcible entry cache. There are a handful of modifications and conversions that we can apply to the saw to make it preform more efficient. The outboard saw conversion is one of the simplest and most effective modifications to make the saw a more versatile forcible entry tool. The outboard saw conversion involves moving the saw blade assembly to the right (or outboard) side of the saw body.
Have you ever tried cutting hinges on a outward opening metal door? Have you ever encountered a frameless glass door with a mortise lock that secures into the floor? The rotary saw is certainly a viable option for both of these situations. When utilizing a non-modified (stock) saw, it is difficult to line the saw blade perfectly perpendicular to a hinge or floor lock that is being defeated. As a result, the blade ends up cutting at an angle and tends to more likely bind up. The outboard saw conversion puts the blade flush with the saw’s body, allowing it to cut easy in tight places saving time and energy. Another situation where it may be beneficial to have an outboard saw is when cutting locks in recessed doorways.
If you have more then one metal cutting rotary saw on the rig, you should consider applying the outboard conversion to one of them. The conversion is still a viable option even if you only carry one metal cutting saw on your rig. The outboard saw gives us versatility while not compromising any other functions. The outboard saw still operates the same as a stock saw. There is however a noticeable change in how the saw “feels” to the operator since changing the location of the blade effects the gyroscopic effect on the saw. It is important to make sure everyone has operated the saw in a training setting before using it on an actual emergency run.
The photos below show the benefit when cutting a hinge with an outboard saw. The first photo shows an unmodified saw, and the second shows the outboard saw. You can clearly see how the outboard saw cuts the hinge at a better, more perpendicular angle.
The next photos show how the outboard saw cuts the floor lock. The first photo shows an unmodified saw, and the second shows the outboard saw. Again, you can clearly see how the outboard saw cuts the lock at a better, more perpendicular angle.
The outboard conversion can be accomplished with just a few quick and easy steps. All you need is the scrench that came with your saw, or a flat-head screwdriver and ratchet. Click here to download a complete step-by-step guide to perform the outboard saw conversion in PDF format.No comments
Jimm Walsh was just interviewed on the Jumpseat Radio Podcast. The Host Ryan Pennington asked Jimm what VentEnterSearch.com’s tagline The Lost Art of the Fire Service is all about click here to hear the episode. (Once you click on the link, scroll down to under the bio and you’ll see the icon to play the podcast.)
Some of the other topics include:
Aggressive Search Techniques
Pro-Active Laddering of the buildings, even if NOT on Fire.
Tips for each Jumpseat Firefighter to improve their Truck Comapny Functions
Our friend Andrew Brassard from Brotherhood Instructors LLC submitted this video showing the Padlock Twist. A padlocked chain is an extremely common forcible entry situation we may come across. One popular method of defeating this set-up is to try and drive the padlock off the chain by inserting the pike of the halligan into the shackle of the lock, and striking with another tool. However this method is not always the most efficient because the chain tends to act as a shock absorber and absorbs most of the force you are generating into the lock. Another and perhaps more common method is to simply use a saw or bolt cutters to cut the lock… but what if you don’t have a saw on your rig? Or you find yourself operating a long distance from the rig and don’t want to waste time going back to grab a tool?
As you can see in the video, you begin by simply twisting the chain to remove the slack. Once the slack is taken out, you place the forks of the halligan on the shackle of the padlock and keep twisting until the lock fails. The method in the video works really well for both low and medium security padlocks, which are typically the most common we come across due to their low price. The most beneficial part of this method is that it is a single person technique. One common use may be when the outside vent firefighter encounters a chain and padlock when accessing the rear yard at a private dwelling and may only have a hook and halligan to work with.
Knowing how to utilize your tools in a variety of different ways is an essential fireground skill. Simply knowing how to apply the maximum amount of mechanical advantage in different situations will make us more efficient and effective on the fireground.No comments
Cellular telephone transmission sites are most commonly found on standalone towers, however, building rooftop cellular transmission sites are becoming more and more common. These rooftop transmission sites are certainly something that all firefighters should be aware of. These sites pose a unique threat to firefighters operating on or near the roof in the form of a Radio Frequency (RF) exposure.
Most commonly the cellular transmission sites that are found on towers are made of of 3 sectors (or panels) of antennas 120 degrees from each other. Typically when they are installed on roofs, the antennas consist of 4 sectors (or panels) of antennas, one for each side of the building. Each sector (or panel) is typically made of of 3 high gain antennas, with the middle one dedicated to transmitting and the two outside ones dedicated to receiving. With the increase demand for bandwidth of today’s phones (think internet access), many cellular providers are increasing to 4 antennas per sector.
The most common frequency ranges that are found on cellular transmission sites are in the 824-849MHz, 869-894MHz and 1850-1990-MHz bands. Just for comparison, the most common public safety radios operate in the 769MHz-800MHz, 806-824MHz, and 851-854MHz range. As you can see our radios operate very close to some of the cell phone frequency spectrum, and that’s what that whole re-banding thing was all about. It is worth mentioning that our radios operate at a much lower power (3-5 watts) compared to cellular transmission sites (up to 500 watts) so there are no RF energy issues to be concerned with in regards to our radios.
One of the most challenging parts of working around these antennas is simply identifying their presence. Often times the antennas are hidden behind fiberglass covers for aesthetic purposes. So easily detecting their presence from the street might be next to impossible. One of the only obvious indications of their presence may like one of the signs shown below posted on the stairwell door providing roof access. This sign is required by the FCC when certain levels of RF energy are present on the roof. Unfortunately this sign will not alert us when we are accessing the roof via the aerial ladder.
There are many variables when determining the amount of RF energy that is present at each antenna site. It depends on the power output and number of radio channels or transmitters that are present at each site. The FCC permits up to 500 watts per channel, but often times only 100 watts is found in rooftop sites. For our purposes on the fireground it really doesn’t matter the actual power output. We should treat every cellular transmission site like it is capable of producing high levels of RF energy that can significantly hurt us.
The RF energy produced from these antennas is non-ionizing radiation, similar to the energy found in a microwave oven. So the major concern of RF energy exposure is over heating of the human body. Just like those leftovers in the microwave, if your body is in the path of the RF energy you could be heated to a well-done temperature. If you must be around the antenna, a good rule of thumb is to remain behind or under the actual panel of the antenna. The reason this works is because cellular transmission antennas utilize very directional antennas. Essentially all of the energy is focused out the front of the antenna. This is why being below or behind the panel is the safest place if you must be near it for any reason.You never want to allow your head to be in line with the transmission pattern of the antenna. The further away you are, the less energy you will be exposed to. It should go without saying, but never touch the actual antenna.
Besides the RF issues, these cellular sites often present other hazards such as tripping hazards and additional electrical issues. The cable trays mounted on the roof could easily be obscured by smoke causing a tripping hazard. Most radio rooms will also be serviced by a backup generator that will be independent of the buildings primary electrical system. In addition, the site will have battery backup systems as well. So it would be very difficult for us to ensure that all power has been isolated from the equipment.
One of the best things to remember when operating around rooftop cellular antennas is to simply to apply the HazMat mantra of Time, Distance, Shielding. While RF shields are available for certain applications, they have no practical use for us while accessing a rooftop during fireground operations. Simply stay as far away from the antenna as you can, and if for any reason to need to pass in front of one, do it quickly. Time and Distance can minimize your exposure.
If you are curious about the possible location of any cellular transmission sites in your area, there is a free website that will show all sites within a 4 mile radius of a particular address. It may not list every single site, but it’s pretty comprehensive and certainly seems like a fairly accurate tool for planning purposes.
The picture above shows a “hidden” cellular transmission site. The four squares are found on each side of the building are each hiding one panel antenna. This particular building has a total of 16 antennas, four on each side. If you found yourself operating on the roof, you could see that your head could be very close to the transmission pattern of the antenna.
The picture above shows a two different cellular transmission setups. There are two sets of panels that are focused on side A of the building. This just shows that there are two different cellular providers on this building. You can just barely begin to see one of the panels on the D side as well. This particular style of installation is more hazardous to a crew accessing the rooftop from the aerial ladder. You would be perfectly safe to be standing behind these panels since the RF energy is focused out the front. Having said that, if you don’t need to be close to the antenna, simply stay away. Look at the windows just underneath the antenna panels, it just demonstrates how the RF energy is in fact focused straight out.
The picture above shows another style of roof top transmission sites. This particular setup is more hazardous to the team operating on the roof. Although its hard to tell from the picture. These panels are slightly set back on the roof. This creates a situation where someone could walk directly in front of the panel and directly into the transmission beam. You can also see that the radio room structure has been added to the rooftop of the building. This style of installation would have the trip hazard from the cable trays present in-between the radio room structure and the antennas.No comments
Assist Chief. Dennis Baker Jr. from Baden (PA) sent in these pictures of how they set up their cribbing. He made sure to point out that Lt. Tim Firich was actually the one who should get the credit for the idea. They color-coded their cribbing based on length. The ones pictured happen to be 18” 6×6’s. As you can see in the picture below the paint color actually goes about an inch onto the side of the cribbing as well. This little addition makes it easy to visually see from a distance that the cribbing tower is square.
The handles are 1 inch webbing cut at 16 inches long and secured with a fender washer and 1 1/4″ wood screw. They overlapped the webbing and used a soldering pencil to burn the whole for the screw. This will prevent the webbing from unraveling near the screw hole.
The idea of color-coding could be implemented a few different ways: either length or lumber size. Even wedges could be coded with different color paint, or even a different color of webbing. For example if you painted your 4×4’s red, the 4×4 wedges could also be red, but with a different color webbing. The important thing is not of over think it. Come up with a standardized marking system that works for you and your agency.5 comments
Bud Henkels from the Montgomery County (PA) Fire Academy sent in this amazing building construction prop that he built for his Firefighter Awareness to Wood Frame Construction class. The focal point of the presentation is this scale model (1 ” = 1′) that shows the students wood frame construction from foundation to ridgepole.
On one side it incorporates modern day platform framing and on the other side, later day balloon framing. Having both different construction types present make it easy to show the differences with each style. The prop includes the ability to add a real time smoke conditions that demonstrate how differently smoke and fire can travel through each type of construction. While the prop is certainly a major part of it, the program also includes a 3-hour power point program that focuses on building terminology and other building constriction methods.
Bud’s previous experience as a carpenter and contractor certainly shows through with this quality craftsmanship. Wile making a quality prop like this will certainly take some time; it doesn’t have to cost much money. There is a good chance that someone around your firehouse has the talent and ability to make something similar. This prop, sitting on a table in the firehouse or training room can be referred to during many formal classes, and even more importantly those informal kitchen table classes. Instead of doing some third grade quality drawing on the dry erase board; pointing something out on a prop like this would certainly enhance the learning opportunity.5 comments
This post is not at all meant to throw stones at the recent news of multiple aerial failures. It’s also not meant to make any accusations of responsibility; rather it is just a great time to ask this question:
Who performs the preventative maintenance and inspections of your aerial device?
Is it the departmental or municipal garage? Is it an outside vendor? Or is it you and your crews? Look back at those choices, only one group’s life is on the line… Why would the crews whose life safety depends on the aerial not perform their own lubrication and inspections of the aerial? We understand that some department’s administration may not “allow” for this to happen, but they cannot (and should not) prevent us from at least performing our own DETAILED inspection. We are not talking about simply operating the aerial on a daily/weekly check, we are talking about REALLY checking it out. When was the last time you looked at every single surface of the aerial including but not limited to: wear plates, wire rope, pulleys, hydraulic cylinders and hoses?
Every apparatus manufacture provides detailed documentation on the lubrication process. This list also itemizes each different lube that is required for each surface and component. How do you think you mechanics learned how to do it? They read about it and were maybe shown the process by someone else. Why don’t you have them teach you how to do the same thing? Even if they wont let you take over the lubrication of the aerial, have them teach you how to PROPERLY inspect it. Ask what every simple component does; watch how the pulleys and wire rope move when the aerial is in operation. Make sure you understand everything you possibly can about this piece of equipment that rely on.
This is my aerial. There are many like it but this one is mine. My aerial is my best friend. It is my life. I must master it as I must master my life.3 comments
VentEnterSearch’s own Jimm Walsh will be presenting From the Jump Seat to the Front Seat on July 31, 2014 at the Third Annual Mickel Begg Leadership and Safety Conference. The conference is being held in honor and reverence to the memories of Lieutenant John Mickel and Firefighter Dallas Begg. The conference will be held in Celebration Florida from July 29 – 31 and will also include presentations by Curt Isakson, Michael Ciampo. The conference is hosted by Osceola County Professional Firefighters Association IAFF Local 3284, and the Central Florida FOOLS. All proceeds from the conference benefit the Mickel-Begg Scholarship Fund. Please click here to download the flyer for additional information and registration information.No comments
